Negative pressure fishing tool

Number:



Specifications:



Surface treatment:



Processing methods:



Supply standards:



Product introduction:

The negative pressure fishing tool is a spray garbage collection basket, which is a tool for making the strong vacuum suction debris into the salvage barrel through the flow control. The efficient filter can allow the fluid to be discharged into the annulus, leaving the crumbs in the garbage collection bin, so that the bottom hole can be recovered and the fast jet produced can play the role of cleaning the shaft lining.

SIZE

OD

ID

Length

Max OD

Casing size

Thread

5 1/2″

Ø115mm

0.8-1.0m3/min

2000mm

Ø65mm

Ø121-Ø127mm

2 7/8 IF.BxP

7″

Ø146mm

1.2-1.5m3/min

2500mm

Ø75mm

Ø154-Ø168mm

3 1/2 IF.BxP
